ENGINE:
TRANSMISSION:
CAPACITY:- Technical specifications
- Optionals
| Engine | Perkins 403.07 diesel 3 cylinders (Hp 18,5 / Kw 13,6) water cooled Kubota V 1305 diesel 3 cylinders (Hp 24,8 / Kw 18,5) water cooledd |
| Start | electric |
| Digital display | with instruments and service lights |
| Transmission | hydrostatic with pistons pumps |
| Hydraulic motors | wheel motors Poclain |
| Brakes | negative |
| Controls | joystick for speed-and corse control, with servo-control |
| Frame | with slides and quick connections for accessories |
| Driver's seat | with suspensions and safety belt |
| Safety roll bar | APPROVED |
| Guide roller | n. 8 in cast iron with unthreading pins assembled on bearings |
| Tracks | rubber |
| Spring tensioner | for the tracks |
| Heat exchanger | combined water-hydraulic oil |
| 1 hydraulic connection | with gear pump from 0 to 40 lt/min with flow regulator |
| 10 hydraulic connections | double or simple effect from 18 lt/min |
| Overall dimensions | mm. 1970x680/900x2170 |
| Weight | Kg. 500/800 |
| Capacity | Kg. 600 |
| Speed | from 0 to 7 Km/h by gradual change |
| Treated on all metallic parts | powder painting |
Dumper loading platform, with double effect cylinder hydraulic tipping
Front roller with electro-hydraulic control
Hoist for Pto
Retractable hoist for Pto
Butt irroration barrow with hose reel and pump
Guide roller with hydraulic tilting
Pto 540 rev/min for engines Kubota V 1305
Pto 540 rev/min for engines Perkins 403.07
Pto onverter
Reversible driving system
Digital display with speedometer
Driving system with speed regulator
Atomizer
Steel tracks
