ENGINE:
TRANSMISSION:- Technical specifications
- Optionals
| Engine | Perkins 403.07 diesel 3 cylinders (HP 18,5 / Kw 13,6) water cooled Kubota V 1305 diesel 3 cylinders (HP 24,8 / Kw 18,5) water cooled |
| Start | electric |
| Dashboard | indicator service lights for oil, alternator, pto and hour-counter |
| Transmission | hydrostatic with pistons pumps |
| Hydraulic motors | wheel motors Poclain |
| Brakes | negative |
| Controls | 2 lever for speed-and corse control with servo-control |
| Seat | with safety belts |
| Safety roll bar | APPROVED |
| Guide roller | with unthreading pins assembled on bearings |
| Tracks | rubber |
| Spring tensioner | for the tracks |
| Heat exchanger | combined water-hydraulic oil |
| 1 hydraulic connection | with gear pump from 0 to 40 lt/min with flow regulator |
| 4/6 hydraulic connections | double or simple effect from 18 lt/min |
| Hoist | three poit lift with adjustable fast connections on bar |
| Overall dimensions | mm. 1900x850x2000 |
| Weight | Kg. 450/850 |
| Lift capacity | Kg. 300 |
| Speed | from 0 to 7 Km/h by gradual change |
| Treated on all metallic parts | powder painting |
Hydraulic third connection
Pto inverter for engine Perkins 403.07
Reverse-drive system
Pto sx 540 rev/min for engine Perkins 403.07
Pto 540 rev/min for engine Kubota V 1305
